Swing Over Bed:

410mm 16"

◆ 3 jaw chuck

Swing Over Cross Slide:

255mm 10"

◆ 4 jaw chuck

Swing in Gap:

580mm 23"

◆ Face plate

Center Height:

205mm 8"

◆ Chasing dial indicator

Distance Between Centers:

1000mm 40"/1500mm 60"

◆ Steady rest

Bed Width:

 250mm 10"

◆ Follow rest

Max. Section of Tool:

20 x 20mm 3/4" x 3/4"

◆ Dead centers

Max. Travel of Cross Slide:

210mm 8-1/2"

◆ Full length splash guard

Max. Travel of Compound Rest:

140mm 5-1/2"

◆ Coolant system

Spindle Bore:

52mm 2"

◆ Brake system

Spindle Nose:

D1-6

◆ 4 jaw chuck

Taper of Spindle Bore:

M.T.NO.6

◆ Reduction sleeve

Range of Spindle Speed:

16 changs 45-1800r/min

◆ Tool box & tools

Leadscrew Pitch/Diameter:

6T.P.I./28mm

Inch Threads Range:

2-72T.P.I. (NO.45)

Metric Threads Range:

0.2-14mm (NO.39)

Inch Longitudinal Feeds Range:

0.002"-0.067"/Rev(17 Nos)

Metric Longitudinal Feeds Range:

0.05-1.77mm/Rev(17 Nos)

Inch Cross Feeds Range:

0.001"-0.0335"/Rev(17 Nos)

OPTIONAL ACCESSORIES

Metric Cross Feeds Range:

 0.025-0.85mm/Rev(17 Nos)

◆ Taper turning attachment

Module Pitches Range:

0.3-3.5M.P.(18 Nos)

◆ Live center

Diametrical Pitches Range:

 8-44D.P.(21 Nos)

◆ Work light

Travel of Tailstock Sleeve:

 120mm 4-3/4"

◆ Leadscrew guard

Dia. of Tailstock Sleeve:

50mm 2"

◆ Digital readout

Morse Taper of Tailstock Sleeve:

M.T.NO.4

◆ Quick change tool post

Power of Main Motor:

 2.2/3.3kw (optional 3/4.5kw)

◆ Chuck guard

Power of Coolant Pump:

4P,3PH 90W

◆ Digital readout (2 Axis)

Overall Dimension(L x W x H)mm:

1940 x 850 x 1320mm

◆ Drill chuck + Drill arbor

Packing Size (L x W x H)mm:

2070 x 940 x 1600mm

Net Weight/Gross Weight:

1550/1760kg
