500

750

Max. swing diameter

mm

Φ220

Distance between centers

mm

500

750

Center height

mm

125

Max. grinding diameter

mm

Φ200

Range of internal grinding

mm

Φ13~Φ80

(Only for CUC2050)

Max. loading between centers

kg

50

CNC System

  -

GSK/KND/Mitsubishi/FANUC

(Depends on customer’s request)

Wheel head

OD × W × ID

mm

Φ400× (32~50) ×Φ203

Linear speed

m/sec

45

Total travel

mm

200

Feed speed

mm/min

0.1~4000

Min. setting unit

mm

0.001

Worktable

Type

-

Two-layer taper adjustable worktable

Total travel

mm

590

840

Feed speed

mm/min

0.1~4000

Min. setting unit

mm

0.001

Work head

Taper

-

MT4

Rotating speed

r/min

30-300 (stepless)

Tailstock

Taper

-

MT4

Travel of center

mm

25 (Manual type tailstock)

60 (Hydraulic type tailstock)

Electrical system

Power of wheel spindle motor

kW

4

Torque of wheel -feeding motor

N.m

14

Torque of worktable feeding motor

N.m

9

Power of work head spindle motor

kW

0.75 (6P)

Hydraulic pump motor

kW

0.75 (4P)

Others

Hydraulic oil tank & lubricant tank

L

45

N.W./G.W.

kg

2500/3300

2900/3700

Packing dimension (L×W×H)

cm

320×200×225

340×200×225
